Introduction
Teff Flour Milling Machine
If you need to make superfine teff flour, like 100 mesh, 150 mesh, 200 mesh...etc
our BSP air classifier mill is the machine you will need.
Our BSP teff grinding machine is made by stainless steel, food grade.
It has 5 parts to make the production continuous.
Mill part, cyclone, filter box, fan,and control box.
The grinding is dust-free and continuous.
And the dust will be collected in our filter box.
There is air classifier inside the mill chamber, which can make sure the powder is superfine and very smooth,soft, and even.
Machine video
This video is our BSP-350 ACM mill for grinding superfine teff flour.
Besides, this machine can also grind other materials like rice,wheat,corn,herbs....etc
Technical Data
Technical Data of BSP teff grinding machine flour
Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
Input size(mm) | < 15 | < 15 | < 15 | < 15 |
Powder fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
Crush motor(kw) | 7.5/11 | 15/18.5 | 22/30/37 | 45/75 |
Grade motor(kw) | 1.1 | 2.2 | 7.5 | 11 |
Blower(kw) | 5.5 | 7.5 | 18.5 | 37 |
Feed motor(kw) | 0.37 | 0.75 | 0.75 | 1.1 |
Discharge motor(kw) | 0.75 | 0.75 | 0.75 | 1.1 |
Speed of principle axis (rpm) | -6500 | -5600 | -4400 | -3100 |
Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
Overall size(L*W*H)(mm) | 5000×1400×2800 | 5400×1500×2900 | 6600×2000×3600 | 9800×2700×4900 |
Weight(kg) | 1600 | 1800 | 2300 | 3100 |
This is picture of our BSP-750 teff flour milling machine
you can see how big the machine is.
other machines
If you are looking for a small teff flour milling machine or medium fine teff flour machine,
you can also choose the machines below.
This machine can make 12~100 mesh teff flour.
This one is good for small production, and the teff powder size can also be 12~100 mesh.
