Industrial Herb & Spice Mill Grinder Machine

          How to choose industrial spice grinding machinery? To choose the right spice grinding machine for you, you need to consider two factors: spice oil content and target spice powder particle size.Low-oil spice examples are: ginger, turmeric,cinnamon,garlic,onion;Mid-oil spice examples are: chilli,cumin,coriander seeds,clove,pepper;High-oil spice examples are: mustard seeds,clove,nutmeg.For low oil spice, no matter what spice grinder machines you choose, they can grind them into powder, the only difference is powder size, capacity, and grinding effect.Hammer mill,air classifier mill,and pin mill is the popular choice.Hammer mill and the pin mill can make 20~80 mesh spice powder, and ACM mill can make 60~300 mesh spice powder.For Mid-oil spices,not all machines are okay.But Brightsail BSDF advanced hammer mill and high-speed pin mill has no sieve or screen in mill chamber.For high oil spices,pin mill and cryogenic mill is okay.Cryogenic mill means: while grinding, liquid nitrogen shall be connected into the mill chamber,to make the grinding chamber super cold,so the oil won’t go out.Target spice powder particle size20~40 mesh spice powder.To make 30~80 mesh spice powder, air classifier mill, BSDF advanced hammer mill, pin mill and cryogenic mill is okay.60~300 mesh is superfine,to make such type spice powder, only air classifier mill and cryogenic mill is okay.


Spice Grinder Machine Applications

Materials
When you purchase an industrial pulverizer machine, you can expect to grind the following materials:

Hammer Mill Grinder Benefits

  • It can grind almost all kinds of spices and herbs into powder;
  • Its application is very wide, from food to feed, chemical and pharmaceutical;
  • Without cyclone discharge system, the mill part can work alone,too;
  • Its noise is lower compared with pin mill and air classifier mill;
  • It can also make flakes and granules if change bigger screen and reduce the rotor speed.
  • It can work with our BSP air classifier mill as a primary crusher.


Models of Size Spice Grinder Machine for Sale

Air Classifier Mill

With CE 60~2500 mesh stainless steel Air Classifier Mill ACM grinder Classifying Mill from China.
Advantage:

1. There is air classifier in mill chamer.

2. The particle size distribution is relatively concentrated.

3. If you want to change the setting of the machine, you can do it while working.

4. Just set the inverter's frequency, you can change the powder's particle size.

 for example, if you need fine powder, you can try 20Hz firstly,

 if powder not enough, you can try 25Hz,28Hz...etc;

 If you need bigger powder, you can try 15Hz, 12Hz...etc.

Model   BSP-350     BSP-450     BSP-500     BSP-750
Capacity(kg/h) 20-200 40-500 60-1000 120-2000
Input Size(mm) < 15 < 15 < 15 < 15
Powder Fineness(mesh) 60-2500 60-2500 60-2500 60-2500
Crush Motor(kw) 7.5/11/15 15/18.5/22 22/30/37 45/55/75

Classifier Motor(kw)

1.5 4 5.5 11
Blower(kw) 7.5 11 18.5 37
Feed Motor(kw) 0.55 0.75 0.75 1.1
Discharge Motor(kw) 0.75 0.75 0.75/1.1 1.1/1.5
Speed of Principle Axis (rpm) -6500 -5600 -4400 -3100
Grading Impeller speed(rpm) 4000 4000 3500 3000
Overall Size(L*W*H)(mm) 5000×1400×2800 5400×1500×2900 6600×2000×3600 9800×2700×4900
Weight(kg) 1600 1800 2300 3100
Total Motor Usually (KW) 21.3 31.3 55.85 105.6

Spice and Herb Powder Hammer Mill

  Spice and herb power hammer with CE 12~120 mesh stainless steel food grade spice powder making machine herb powder grinder machine.

  This machine has a very good effect for different kinds of spices,like Chili, pepper, black pepper, white pepper, green pepper, cinnamon, cumin, bandits, cinnamon, nutmeg, cardamom, red yeast rice, red pepper, garlic, star anise, cloves, Amomum Tsaoko, geraniol, turmeric, ginger, fennel, anise, angelica and other material with high content of oil or fiber.For root,herb and leaf, the grinding effect is also good.

For flour, like rice,cassava,corn...its grinding effect is nice.

Model

BS-200

BS-320

BS-400

BS-630

BS-880

BS-1000

Capacity (kg/hr)

50~300

70~500

80~1200

400~1800

800~2500

1000~3000

Grind size(mesh)

12-120

12-120

12-120

12-120

12-120

12-120

Main crush motor (KW)

7.5

11

22

37

45

55

Discharge motor (KW)

0.75

0.75

0.75

1.1

1.5

1.5

Blower motor (KW)

3

3

15

18.5

18.5

30

Machine material

SS304

Remark:

1) BS-200 and BS-320 is joint type, and blower is set above the filter box.

2) Capacity is affected by the raw material and target powder size a lot.

3) About overall size and drawing, please contact our sales to get it.

3-stage Hammer Mill

Our 3-stage hammer mill.

It combines coarse crusher,middle fine milling fine milling area(3 milling areas)together. Material will be milled three times at the same time.

For spices (like chili, turmeric, coriander seeds, cumin),  powder can be 20~80 mesh;

For grains (like rice, cassava, chickpea, besan,wheat....etc)  powder can be 20~150 mesh.

So, if you are interested in spice grinder(spice  powder mill machine),our BSDF spice powder making  machine is a very good choice.

Model

BSDF-350

BSDF-450

BSDF-550

BSDF-650

BSDF-750

Rotor speed(rpm)

3500-4500

3300-4200

2900-3600

2400-3100

2100-2700

Grind motor(Kw)

22

37

45

55

75

Feed motor(Kw)

0.25

0.25

0.25

0.25

0.25

Discharge motor(Kw)

0.75

0.75

1.1

1.1

1.5

Blower(Kw)

7.5

11

15

18.5

18.5

Grind fineness(mesh)

20-120

20-120

20-120

20-120

20-120

Capacity(Kg/hr)

100-200

300-500

400-800

600-900

800-1300

Pin Mill Grinder

  Pin mill's application is very wide, it can grind food,chemicals mainly, and it can make 40~1000 mesh powder depending on the raw material.

  Our pin mill has two grind discs.They rotate again each other with a very high speed, so it can make fine powder.There is no sieve, no screens in mill chamber.

  So, It can grind material with a little sugar and oil.No need to worry the powder gets stuck inside the mill chamber.

Model BSZ-350 BSZ-450 BSZ-550
Capacity (kg/h) 60-200 150-500 230-700
Feed size (mm) < 15 < 15 < 15
Output size (mesh) 40~200 40~200 40~200
cavity  disc crush motor(KW) 11 18.5 22
door disc crush motor (KW) 15 22 30
feed screw motor (KW) 0.37 0.55 0.75
Speed  (rpm) 12000 9600 8400

High Efficient Hammer Mill

High-efficient Mill stainless steel hammer mill is like Fitz mill, it is good as a Pharmaceutical powder mill and herbal grinding machine.

BSF High-efficient Mill is a kind of small hammer mill, learned and improved from Fitz mill.This machine is usually used as a Pharmaceutical grinder(Pharmaceutical powder mill)

Application:

1) Pharmaceutical use, to make granules and powder.

2) Food use, for example, herbs, Chinese medicine, spices,leaves, grains...etc


Model BSF-8 BSF-16 BSF-32
Capacity (kg/h) 10-100 50-300 100-500
Fineness of powder (mesh) 12-120 12-120 12-120
Power (KW) 3 7.5 11
Speed (rpm) 2350-4360 1000-2400-4400 1000-2400-4400
Overall size (L*W*H) 1050*600*1600 1100*860*1600 1280*950*1600
Weight (kg) 150 250 320

Seeds Grinding Machine

BS seeds grinding machine grinder for dry seeds from Brightsail can grind sesame seeds, mustard seeds, flax seeds and nuts into seeds powder or nut powder.

BS Seeds Grinder Machine is well designed and developed by Brightsail. And it is also called BS roller crusher.BS roller crusher is specially designed for the materials that contain much oil content, such as sesame, peanut and almond,mustard seeds... etc.
It can grind such materials at normal temperature.

It is widely application in food industry.

Besides,there are two types of roller to crush different raw materials.


Model BS150-3 BS150-4 BS250-3 BS250-4 BS500-3 BS500-4
Length(mm) 780 780 920 920 1340 1340
Width(mm) 670 670 720 720 1210 1210
Height(mm) 1600 1850 1750 2000 2000 2250
Weight(kg) 350 520 580 750 1200 1400
Capacity(kg/h) 50-200 50-200 100-400 100-400 200-500 200-500
Powder size (mesh) 12~60 12~60 12~60 12~60 12~60 12~60
Motor (kw) 2.2 3 5.5 7.5 11 15
Roller Diameter(mm) ϕ150 ϕ150 ϕ150 ϕ150 ϕ219 ϕ219
Roller Length(mm) 150 150 250 250 500 500

BS cryogenic mill

Cryogenic mill machine can grind high oily spices into fine powder, it connects liquid nitrogen while working).Cryogenic mill machine has very wide application. With connecting liquid nitrogen, it can make quality food powder, and it can also grind plastics.

Application of BS cryogenic grinding machine

1) Chemical industry and coating field;

2) Food and health care products;

3) Recycling: low melting point plastics, high self-lubricating materials, waste rubber, raw rubber and raw rubber;

4)The hot melt adhesive like EVA EAA TPU LDPE and other low melting point colloids.

Model BS-200 BS-500
Grind motor (KW) 7.5 45
Input material size (mm) 5-15
Medium liquid nitrogen
Temperature (℃) - 196 ~ 0
Fineness (mesh) 10~700 (depends on materials)
Capacity (kg/hr) 30~150 (depends on material) 100~1000 (depends on materials)
Grinding chamber φ (mm) 180 500
Feed & Discharge by screw feede
Remark We have bigger models,too. please contact us to get the details of them. (because cryogenic mill is more like a system rather than a single machine)
