Product Introduction
BSZ hemp flour grinder
BSZ pin mill is a kind of hemp grinders.
It can grind hemp seeds into fine hemp flour around 60 mesh, or 70 mesh, or 80 mesh.
The hemp seeds shall be removed oil firstly and it will become a seeds cake like below.
BSZ hemp flour grinder has two grind discs,
and the rotor speed is very fast, can reach 12000 rpm
The two grind discs rotate against each other to grind the dry hemp oil seeds cake into fine powder.
Main Features
Features of our our BSZ hemp fine grinding powder grinder machine.
1) Simple structure.
2) Easy to clean and install.
3) No need screen in grind chamber, change powder size by changing speed.
4) It can grind material with high sugar or high oil content.
Technical Data
Technical Data of BSZ hemp grinder
| Model | BSZ-350 | BSZ-450 | BSZ-550 |
| Capacity (kg/h) | 60-200 | 150-500 | 230-700 |
| Feed size (mm) | < 15 | < 15 | < 15 |
| Output size (mesh) | 40~200 | 40~200 | 40~200 |
| cavity disc crush motor(KW) | 11 | 18.5 | 22 |
| door disc crush motor (KW) | 15 | 22 | 30 |
| feed screw motor (KW) | 0.37 | 0.55 | 0.75 |
| Speed （rpm） | 12000 | 9600 | 8400 |
If
work video
This is video of our BSZ-350 Hemp Flour Grinder
In the video,we crush the big seeds cake into small granules, then we grind it into fine hemp flour by our BSZ hemp grinder.
This is video of our BSZ-350 pin mill unit for grinding coffee bean powder for reference.
FAQ
Q: How to install the BSZ hemp flour mill?
A: We provide English electric diagram, and English manual.
99% clients can install the machine by themselves under our guidance.
Q: Can the machine's voltage be customized?
A: Yes, sure. Like 220V,400V, 480V, 600Hz....we can do it.
Q: Which city are you from?
A: We are in Wuxi city, which is near Shanghai, the distance is only ~150KM.
By car, it takes ~2 hours from our city to Shanghai.
Q: What is the brand of the motors, inverters and electrical parts?
A: If customers need more cost-effective machine, we will recommend good quality Chinese brand. If customers have enough budget and want better parts, we will use Siemens,ABB,Schneider,WEG,SEW...etc
