Introduction
This chili grinding machine with high rotation speed.,can be widely used in medicine, chemical industry, food and other industries.
This chili grinder machine also has a good grinding effect on spices, and most spice powders can reach 30~40 mesh. Besides spices, it can also be used to grind dried leaves, chickpeas, sugar and many other materials.
Working Method
The target material is crushed by cutting and grinding with a high-speed cutting tool. Knife type can be selected according to different material and particle size.
Advantages
1. Simple structure
2. Convenient installation
3. Stable operation
4. Easy to move
5. Low noise
6. High grinding efficiency
7. High speed, can be made into fine powder.
Technical Data
Model | BS-180 | BS-250 | BS-300 | BS-350 |
Feed size (mm) | < 10 (granule) < 15*40*2 (leaf) | < 10 (granule) < 15*40*2 (leaf) | < 10 (granule) < 15*40*2 (leaf) | < 10 (granule) < 15*40*2 (leaf) |
Grind fineness (mesh) | 10-120 | 10-120 | 10-120 | 10-120 |
Capacity(kg/hr) | 3-50 | 10-100 | 20-200 | 30-300 |
Grind chamber diameter(mm) | 200 | 270 | 330 | 380 |
Rotor speed (rpm) | 5900/8600 | 4200/6200 | 2600~5100 | 2200~4400 |
Motor (kw) | 2.2 | 5.5 | 7.5 | 11 |
Overall size (mm) | 840*470*1020 | 930*600*1200 | 1000*650*1500 | 1150*700*1600 |
Weight(kg) | 112 | 210 | 296 | 430 |
