BST Through Shape Mixer

This type of mixer is suitable for mixing of target materials in powder or paste state evenly.
  • BST

  • Brightsail

Availability:
Quantity:

Product Description

    Introducing the BST Through Shape Mixer - the perfect solution for achieving uniform mixing of powdered or pasty materials. Designed with precision and efficiency in mind, this mixer is ideal for a variety of industries, from pharmaceuticals to food processing. With its unique shape and advanced technology, the BST Through Shape Mixer ensures that your materials are blended thoroughly and evenly, every time. Whether you need to mix powders, granules, or other materials, this mixer will deliver consistent results with minimal effort. Trust in the quality and reliability of the BST Through Shape Mixer for all your mixing needs.


Working Method

    The machine is driven by mechanical transmission to make the S-type stirring paddle rotate, push the material to reciprocate, and mix evenly. The electric control is used during operation. The mixing time can be set, the machine will stop automatically, and the motor will be dumped, thus improving the mixing quality of each batch of materials, achieve a high uniformity of mixing.


    Process is highly efficient and produces consistent results every time. The BST Through Shape Mixer is perfect for use in industries such as pharmaceuticals, food processing, and chemical manufacturing.


    Introducing the BST Through Shape Mixer, the ultimate solution for all your mixing needs. This state-of-the-art machine is driven by mechanical transmission, allowing the S-type stirring paddle to rotate and push the material to reciprocate, resulting in a perfectly mixed product every time.


    With its electric control system, the BST Through Shape Mixer is easy to operate and highly efficient. Whether you're working in the pharmaceutical, food processing, or chemical manufacturing industry, this mixer is perfect for all your mixing requirements.


    Thanks to its advanced technology, the BST Through Shape Mixer produces consistent results with every use. Say goodbye to uneven mixing and hello to a perfectly blended product every time.



Advantages

    1. The discharge motor can be used to tilt the stirring tank, which is convenient for discharging.


    2. There are unidirectional thrust ball bearings and radial thrust ball bearings at both ends of the stirring shaft to prevent radial turbulence caused by negative stress.


    3. Improved the seal at both ends of the stirring shaft, which can be completely sealed and does not pollute the material.


    4. When using slow running, it is easy to discharge, and will not cause the phenomenon of excessive tilt of hopper.


    5. Add the raw material to the drum in one time, dry for a period of time, add adhesive or spray, or add the raw material and adhesive to the working container in one time, mix into the ideal soft material.


    6. The mixing tank is made of high-quality stainless steel, which is corrosion-resistant and easy to clean.


    7. Introducing the BST Through Shape Mixer, a professional-grade mixing solution designed for a wide range of applications. With its powerful discharge motor, this mixer makes it easy to tilt the stirring tank and quickly and efficiently discharge your mixture.


   8. The BST Through Shape Mixer is built to last, thanks to its unidirectional thrust ball bearings and radial thrust ball bearings at both ends of the mixing shaft. These bearings greatly reduce friction and help to prolong the service life of the mixer, ensuring that you get the most out of your investment.


   9. The mixing tank of the BST Through Shape Mixer is made of high-quality stainless steel, making it both corrosion-resistant and easy to clean. This ensures that your mixture stays pure and free from contamination, while also making it easy to maintain your mixer over time.


   10. If you're looking for a reliable and professional-grade mixing solution, look no further than the BST Through Shape Mixer. With its powerful discharge motor, advanced bearing technology, and high-quality construction, this mixer is the perfect choice for a wide range of applications. Order yours today and experience the difference for yourself!

Technical Data

Model BST-50 BST-100 BST-150 BST-200 BST-300
Barrel volume(L) 50 100 150 200 300
Mixing speed (rpm) 24 24 24 24 24
Mix motor (KW) 1.5 2.2 3 4 5.5
Dumping motor (KW) 0.75 0.75 0.75 0.75 0.75
Overall size(L*W*H)(mm) 1200×500×600 1400×580×1000 2000×630×1150 2300×750×1350 2700×850×1500
Weight(kg) 320 350 410 450 520
