Hemp Grinder Machine

grinding mill for hemp hemp grinder machine-buy from Brightsail Machinery
Availability:
Quantity:
  • BSZ
  • Brightsail

Product Introduction

BSZ hemp grinder machine


BSZ mill for grinding hemp is used to make hemp flour.

And the hemp flour size can reach 80 mesh.

And the powder size is adjustable.

Hemp flour is made by the hemp seeds oil cake,our BSZ hemp can grind the hemp seeds cake into fine powder.

hemp flour grinder machine



Features of our our BSZ grinding mill for hemp.

1) two grind discs, rotate against each other.

2) small body, high rotor speeds

3) fastest speed can reach 12000 rpm

hemp mill



Technical Data

Technical Data of BSZ hemp mill

ModelBSZ-350BSZ-450BSZ-550
Capacity (kg/h)60-200150-500230-700
Feed size (mm)< 15< 15< 15
Output size (mesh)40~20040~20040~200
cavity  disc crush motor(KW)1118.522
door disc crush motor (KW)152230
feed screw motor (KW)0.370.550.75
Speed  (rpm)1200096008400

If you need big capacity, we also accept cutomized type.

work video

This is video of our BSZ-350 grinding mill for hemp

In the video,we crush the big seeds cake into small granules, then we grind it into fine hemp flour by our BSZ hemp mill.


If you need to grind hemp leaves, hemp stems,

we have hammer mill for hemp as below.

grinding mill for hemp

mill for grinding hemp

FAQ

Q: How to install the BSZ hemp grinder machine?

A: We provide English electric diagram, and English manual.

 99% clients can install the machine by themselves under our guidance.


Q: What is the warranty term?

A: Guarantee against defects in materials and workmanship of equipment and parts for one year. Any parts in need of replacement will be shipped free of charge but labor for installation will not be included. Warranty does not cover abuse or user error and quick-wear parts.


Q: Is the powder size adjustable?
A: Yes, the powder size can be changed by setting the parameter of inverter.

  For example, if you want finer powder, you can try 25 Hz, if not fine enough,then try 30HZ,35Hz...etc


Q: What is the material of the machine?

A: Usually we use Stainless steel 304,

Sometimes,we also use SS316 as customer requests.
